Multilevel protection system against overheating and care for protection. An amplifier like this is a great way to expand your audio system on a tight budget and get a really decent result! Features of the device

Device Features

Digital amplifier (class D)
Ultra-compact body size
Stable work at 4 Ohm and 2 Ohm
Latest high efficiency circuitry
FR-4 Double Layer PCB
Multilevel protection system
SMD surface mount technology
External bass boost remote (V2, V3, V4)
Expanded filters up to 8kHz with simultaneous operation (bandpass) (V2, V3, V4)
Equipped with high-level inputs (V1, V3, V4)

4 channel amplifier allows you to drive many speakers and even a subwoofer.

Stable operation under 2 Ohm load lets your amplifier work continuosly at high loads and with high performance.

Class D in accordance with the latest technological solutions will allow you to obtain the highest quality sound from any acoustic systems.

Bandpass filter lets you tune frequency response for your speaker system with high precision.

Specifications

Features of the model

Stable work at load: 2 and 4 ohms
Bass Boost: 0-6-12dB
Fuse rating: 3 x 30 A
Frequency range: 10Hz ~ 30KHz

Parameters

Peak power: 3000W
Rated power 4 Ohm: STEREO 200W x 4, bridged (MONO): 750W x 2
Rated power 2 Ohm: STEREO 350W x 4
Sensitivity: 200mV
Signal to noise ratio:> 91dB
Harmonic Distortion: (THD) @ 1 kHz (4 ohms) 0.07%

Channel separation

Channel separation:> 45dB
Low pass filter: 10 Hz ~ 8KHz
High pass filter: 10 Hz ~ 8KHz
Number of channels: 4/3/2

General details

Dimensions: 145 x 52 x 274 mm

Power supply

Working voltage: 12V - 14.4V DC
