All parameters of this speaker system have been selected with great attention to both sound and overall reliability, the ability to withstand tangible loads for a long time. The enlarged voice coil allows very serious power to be pumped into the speaker.

Mid-range drivers with large ferrite magnets are designed for loud fronts and fierce everyday life. The diffusers are made of medium density cellulose, traditional for the "stage". The material is light but not very harsh on its own, providing a clear sound and good punch.

The speakers are made in stamped steel baskets, they play clean and loudly, the sound quality is excellent in its price segment! Among the advantages of this model, it should be noted: the brightest MF and high sound detail, significant endurance due to a powerful magnetic system, as well as a small mounting depth, which will allow you to install speakers in any car.

Recommended active crossover 100 Hz - 6 kHz, 12 dB / octave.

Specifications

Sound

• Peak power: 120W
• Rated power: 60W
• Sensitivity: 92 (±1) dB
• Impedance: 4 ohms, minimum resistance 3.7 ohms

Features

• Voice coil: KSV 25 mm
• Cone: Pressed cellulose
• Hanging material: Fabric
• Magnet: Ferrite 80x32x15 mm (11 ounces)
• Frequency range: 140 Hz - 12000 Hz

General details

• Number of bands: 1-way
• Speaker size: 5.25" (13 cm)
• Basket: Stamped steel
• Mounting hole diameter: 124 mm
• Installation depth: 61 mm
• Overall depth: 64 mm
• External diameter: 133 mm
• Operating temperature range: -35 +55 °C

THIELE-SMALL PARAMETERS

• Revc 3Ohm
• FS 166Hz
• SD 88.2cm²
• BL 3.3Tm
• Le 0.00Mh
• QES 1.44
• QMS4.07
• QTS l.06
• SPL 92dB
• VAS 2.0L
• CMS 0.19mm/N
• MMS 4.9g
• Xmax 1.0 mm
